Recycled Cells with DrawnUI — Part II

In the first part we built two drawn lists — a news feed and a chat. After a month I felt more examples could be provided to demonstrate how to create cross-platform recycled drawn lists. Also, while writing this part, I added some more optimizations to the recycling engine.

Previously we showed a hybrid recycling for chat: the adapter wasn’t recycling cells, but the page itself was, by reusing the same cells for new chunks of data. In the following three examples we have RecyclingTemplate="Enabled" everywhere for a more standard approach.

So now, 3 more examples: two of them are demonstrated on the web (thanks Blazor), all three available in MAUI. Sample app, DrawnCells: three lists — a shop grid, a contact list, a banner-card list — with a live overlay at the bottom, so you can watch the list engine work while you scroll. Try it right here — scroll, and switch between the lists with the button:

DrawnCells demo, written in C#, drawn on a SkiaSharp canvas — the same code compiled for the browser. The MAUI app also includes variant C, which is XAML-only.

You will find the small cells code (Variant B) in the new DrawnUI fiddle, where you can play with coding on the SkiaSharp canvas online — everything compiles and renders on the fly in the browser.

The sample app

The DrawnCells sample is a small MAUI app made for this article. One button switches between three lists, and an overlay at the bottom shows the live state of the list engine — the window range, the visible rows, the cached picture.

• A — a shop grid, two columns, loaded page by page from a mock server, on SkiaCachedStack.
• B — a 1000-row contact list on SkiaCachedStack.
• C — a banner-card list built in XAML on a plain stack with MeasureFirst.

All three use even rows, and all three pass 1000 items, so the built-in window is on and you can watch it work. The web demo at the top of this article is this same app compiled for the browser (variants A and B; the XAML variant C is in the MAUI app only).

Here is the starting point, variant C in short form. A SkiaScroll with a SkiaLayout inside a Canvas. Give the layout your items and a cell template:

<draw:Canvas RenderingMode="Accelerated" Gestures="Enabled"
             HorizontalOptions="Fill" VerticalOptions="Fill">

    <draw:SkiaScroll HorizontalOptions="Fill" VerticalOptions="Fill">

        <draw:SkiaLayout
            Type="Column"
            ItemsSource="{Binding Items}"
            RecyclingTemplate="Enabled"
            MeasureItemsStrategy="MeasureFirst"
            Virtualisation="Enabled">

            <draw:SkiaLayout.ItemTemplate>
                <DataTemplate>
                    <!-- your cell -->
                </DataTemplate>
            </draw:SkiaLayout.ItemTemplate>

        </draw:SkiaLayout>
    </draw:SkiaScroll>
</draw:Canvas>

That already recycles. A small set of real cells is created, and cells that leave the screen are reused for the items coming in. It is the drawn equivalent of CollectionView, and this exact setup is fine for many apps.

A note on names: SkiaStack is simply a SkiaLayout with Type="Column". Same control, shorter to write. The XAML above uses the long form.

The problem: big data, small screen

Your list has a million rows. Or your chat loads from a server that never ends. You cannot put all of it on screen. You cannot even keep all of it in memory. So you show a small part, and you slide that part as the user scrolls.

In Part I the chat did this by hand. It kept about 150 messages, loaded more when the user reached an edge, and dropped items from the other side. It worked. But every app with a big list would have to write that same code again.

The library now helps on two levels — and they are two different things:

• The built-in window limits the work: cells, measuring, drawing. Your collection stays whole in memory; the list just stops materializing views for items far from the screen. It engages automatically on a big list, or from the first item with ForceItemsWindow. Part I had nothing like this.
• WindowedSource<T> limits the data: only a bounded slice of items in memory, the rest stays behind your data source. This is what the Part I chat wrote by hand, now a library class.

The built-in window first.

Let the list limit itself

A DrawnUI list can now keep a small window of items near the screen and slide that window over your data. Items far from the screen get no cells, no measuring, no memory.

You do not even switch it on. When your list grows past WindowSourceThreshold items (300 by default), the window turns on by itself. If you want it on from the first item, set one flag:

new ChatMessagesStack
{
    ForceItemsWindow = true,          // window on from the first item
    ItemTemplate = new DataTemplate(() => new ChatCell()),
    ItemsSource = _messages,          // your normal growing collection
    BackgroundMeasurementBatchSize = LoadBatch,
    ItemTemplatePoolSize = MaxItemsInMemory + LoadBatch + 5,
}

ChatMessagesStack is the chat sample’s own stack. Any templated SkiaLayout behaves the same. In that sample LoadBatch is 50 and MaxItemsInMemory is 200.

You keep using your collection as usual — Insert, AddRange — and the list decides which items stay active.

What it limits, and what it does not

Give the list one million items. It limits three things:

• The drawn slice. Drawing works with about three or four screens of items, not with your million.
• The measured structure. Only that slice is measured. A few hundred rows, never a million.
• The cells. Real cell views exist only for that slice.

One thing it does not limit: your own collection. Your million model objects stay in memory. The window only slides over them. For small objects like chat messages this is usually fine.

When even the data is too big

Now picture millions of rows in a database or on a server. You cannot hold the collection at all. So the window must limit the data too, not only the cells. This is exactly what the Part I chat did by hand. The library now has a ready piece for it, WindowedSource<T>:

_window = new LimitedSource(LoadBatch, MaxItemsInMemory);   // WindowedSource<ChatMessage>
_window.SetDataSource(_service);                            // your "server"
_window.SetHost(new SkiaScrollWindowHost(MainScroll, ChatStack));

ChatStack.ForceItemsWindow = false;    // the app owns the window now
ChatStack.ItemsSource = _window.Items; // only the loaded slice, never the full history

MainScroll.LoadMoreCommand    = new Command(() => _window.LoadOlder());
MainScroll.LoadMoreTopCommand = new Command(() => _window.LoadNewer());

_window.Items holds at most MaxItemsInMemory items, 200 in the sample. LoadOlder loads a page of older items and drops the same number of newest ones. LoadNewer does the opposite. The full history stays behind your data source, and the list never sees it. Ten items or ten million behind that source, the memory stays the same 200.

Which case is yours?

Your data	What to do	Who limits memory
Small, fixed	Just load it	Nobody needs to
Grows one way (feed)	AddRange + LoadMoreCommand	Recycling caps cells; collection grows
Large, fits in memory	Built-in window (automatic, or ForceItemsWindow)	The list
Too large for memory	WindowedSource<T>	Your app, with a hard cap

Start with the built-in window. Same result, less code. The chat sample ships both windowed paths behind a developer menu, so you can switch between them live and compare.

Which setup for your list?

The chat is the heavy case. Most lists are lighter. Two questions place almost any list.

Are all rows the same height?

• Yes → keep MeasureItemsStrategy="MeasureFirst". The list measures one cell and reuses that height for every row, so startup is fast. But the heights must be truly identical. Any difference breaks the layout.
• No, like chat messages or feed posts → use MeasureItemsStrategy="MeasureVisible". The list measures only the rows on screen, and measures the rest in the background while the user scrolls. Thousands of uneven rows can still start quickly.

How many cells are on screen at once?

• A few big cells, three or four banner cards per screen → a plain stack is enough. It draws the visible cells one by one each frame, and a few cached draws per frame are cheap.
• Many small cells, twenty contact rows per screen → use SkiaCachedStack. It records all visible cells into one cached picture and draws that single picture while you scroll. One draw instead of twenty.

Together this gives four everyday cases:

Rows	Cells on screen	Use	Why
Even	Few big (cards)	SkiaStack + MeasureFirst	A few cached draws per frame are already cheap
Even	Many small (phone book)	SkiaCachedStack	Twenty draws per frame become one
Uneven	Few big (feed posts)	SkiaStack + MeasureVisible	Same as cards; only the measuring changes
Uneven	Many small (chat)	SkiaCachedStack	Many cells and uneven heights; it measures visible-first by itself

Notes on SkiaCachedStack:

• It is not “the faster stack, use it everywhere”. With a few big cells per screen it only adds work for no gain.
• You do not set a measuring mode on it. It always measures visible-first inside, which is also why it handles uneven rows out of the box.

Think of it as a photo of a tall strip of your list. The strip is taller than the screen. The list records it once, then moves that photo up and down as you scroll. No cell is drawn during those frames. When the screen reaches the edge of the photo, a new photo is recorded.

You can check it is working. Turn on the debug string of the layout. It prints plane [top..bottom] valid=True when a photo is in use, or plane none when there is none and every frame is still drawing cells one by one.

Two properties tune how tall the strip is and how often a new photo is taken — VirtualisationInflatedRatio (default 1.0) and PlaneRefreshRatio (default 0.5). The defaults are good, so leave them for now. How they balance, and how double buffering records the next photo on a background thread.

If your list is short and every item can keep its own view, like MAUI BindableLayout, you do not need recycling at all: MeasureItemsStrategy="MeasureAll", RecyclingTemplate="Disabled", and any container (SkiaStack, SkiaRow, SkiaLayer, SkiaGrid).

For a news feed that grows in one direction, keep an ObservableRangeCollection, wire LoadMoreCommand on the scroll, and AddRange the next page. Never reset the collection:

MainThread.BeginInvokeOnMainThread(() => Items.AddRange(next));  // append, don't reset

Once the collection grows past the threshold, the built-in window starts limiting it, with no extra code.

Why the fast chat turns recycling off

Back to where we started. The chat sample sets RecyclingTemplate="Disabled", in a sample that is all about scroll speed. It was already set this way in Part I — we just never explained why. Here it is.

Recycling has one job: limit how many cell views exist. But the window already limits that. And drawn cells are not native views. A parked drawn cell is a small object holding its measured size and a cached picture. Keeping one cell per item in the window is cheap.

Recycling is not free. Every reused cell has to bind to its new item, measure again (rows are uneven, so the old height cannot be reused), and record its cache again. In a chat with photos, all this work lands in the middle of scrolling — the worst possible moment. On a weak 60Hz test phone that produced a worst frame of about 225ms. With recycling off, that work does not happen during the scroll, and on the same phone the worst frame was about 49ms.

So for a windowed chat: recycling off, one view per item in the window, and a cell pool a little larger than the window plus one incoming page:

ItemTemplatePoolSize = MaxItemsInMemory + LoadBatch + 5   // window + one page + a little extra

If the pool is too small, cells start taking each other’s views while scrolling, and you see flickering and lag.

The cell: code, not bindings

Part I covered this in detail: subclass SkiaDynamicDrawnCell and fill the cell in code inside SetContent, instead of putting a {Binding} on every label. A recycled cell changes its item all the time, and one plain-code update beats a burst of separate binding updates in the middle of a scroll. A short reminder of the shape:

protected override void SetContent(object ctx)
{
    base.SetContent(ctx);

    if (ctx is ChatMessage msg)
    {
        LabelText.Text = msg.Text;
        LabelTime.Text = msg.Time;
        BannerImage.IsVisible = msg.HasImage; // hiding drawn parts is free
    }
}

If the item’s own properties change later, for example a message becomes “read”, override ContextPropertyChanged and update only what changed — Part I shows that too.

Summarizing

Question	Answer
Starting point	SkiaScroll + SkiaLayout + template, recycling on
Rows same height?	Yes → MeasureFirst. No → MeasureVisible
Many cells on screen?	Yes → SkiaCachedStack. No → plain stack
How much data?	Small → load it. Feed → LoadMore. Large → built-in window. Too large → WindowedSource<T>
Windowed + uneven rows?	Turn recycling OFF, size the pool to the window

If any of these other questions is yours, the answer is below:

• “My list is getting huge and scrolling eats memory.” You now do nothing: past 300 items the list starts working with a small slice of your data by itself. One flag if you want it sooner.
• “My data lives on a server and never ends.” Show it through a window of a few hundred items — the app never holds the rest. A ready class for that, WindowedSource<T>, plus the wiring.
• “Which setup do I pick?” Even or uneven rows, few big cards or many small rows — two questions place any list, including MeasureFirst which Part I left out.

What’s next

A new part about grouping, reordering cells and more might follow — depends on your feedback!

Meanwhile — clone the samples, scroll them on your own phone, and try the window on your own list. If something scrolls badly, or the docs leave you guessing, tell me in the comments or open an issue.
